21.5” Medical Grade Bedside Infotainment Terminal
| Display | |
|---|---|
| LCD Size | 21.5” |
| Panel Type | TN |
| Resolution | FHD 1920 x 1080 (16:9) |
| Brightness | 250 cd/m² |
| Contrast Ratio | 1000 : 1 |
| Backlight | LED type |
| Touch Screen | Projected capacitive 10 point multi-touch |
| Viewing Angle | 170° (H)/160° (V) |
| Color Support | 16.7 million colors |
| System | |
| SoC | Intel® Atom® Dual-Core x5-E3930 (1.3GHz, up to 1.8GHz) |
| Memory | 1x DDR3L SO-DIMM 1333/1600/ 1866 MHz up to 8 GB |
| Storage Device | 1x mSATA SSD up to 512G |
| WLAN & Bluetooth | WLAN 802.11 ac/a/b/g/n and Bluetooth 4.0 (optional) |
| OS | Win 10/ Android 6.0/ Linux™ Ubuntu 16.04 |
| I/O Interface | |
| Series Port | 1x RS-232/422/485 |
| Display | 1x HDMI |
| USB | 2x USB 3.0 |
| Ethernet | 1x Gigabit Ethernet |
| Audio | 2x 3W speaker |
| Power Switch | 1x power on/off switch |
| Power | |
| Power Supply | 12V DC Jack / 24V via 3-pin terminal block connector (optional) |
| Power Consumption | – 65W AC-DC Adapter – 60W AC-DC medical certificated adapter (optional) |
| Mechanical& Environmental | |
| Water/Dust Resistance | Front panel: IP65 |
| Operating Temperature | 0°C ~ 40°C |
| Dimensions | 521.9(W) x 321.4(H) x 43.7(D) mm |
| Weight | 3.93 kg |
| Mounting | Standalone; VESA Mount 75 x 75 |
| Certificate | – CE/ FCC Part 18 Class B – EN 60601-1-1 3rd ed. – EN 60601-1-2 4th ed. |
